IGBT 10-30KW Solar charge controller

The controller features a smart tracking algorithm inside that maximizes the energy from the solar PV module(s) and charge the battery. At the same time, the low voltage disconnect function (LVD) will prevent the battery from over discharging. Charging process has been optimized for long battery life and improved system performance. Meanwhile, the comprehensive self-diagnostics and electronic protection functions can prevent damage from installation or system faults.
  • item no.:

    SSCP-XXA-TE
  • lead time:

    3
  • product orgin:

    CHINA
  • shipping port:

    CHINA
  • payment:

    T/T;LC
  • color:

    Orange
products details

IGBT 10-30KW Solar charge controller

2_01

Description of solar charge controller


Technical Data of solar charge controller


System Capability

Model

SSCP-48V

SSCP-96V

SSCP-120V

SSCP-240V

SSCP-360V

SSCP-380V

PV modules Vmp [V]

60-72

120-144

150-180

300-360

450-540

480-576

Module arrays input [array]

Rated charging current [A]

o20  o30  o50   o60   o75   o85   o100

Rated battery bank voltage [V]

 o240  o360  o380  o480  o540

Performance

Consumption at standby [mA]

35

Consumption at night [mA]

15

Topology

Transformerless

OperatingTemperatureRange

-25 to +60 (45 to 60 with derating)

Cooling Method

Convection with double cooling fans

Ambient Humidity

0%98% Non-condensing

Altitude [m]

Up to 2000 (without power derating)

General Data

Terminal

Universal KE series

LCD Display

LCD (16X2charactersgreen backlight)

Display Language

English

Data communication

RS485

Ingress Protection Class

IP20 (indoor)

Noise [dBA]

30

Mounting

Wall mounting type

Dimensions (W*D*H) [mm]

540 *530 *180

Net weight [kg]

15

Standard Warranty [year]

 1



























Product details of solar charge controller




Topology of solar charge controller


Assemly of  solar charge controller


Project case of MPPT solar charge controller

Package and shippment of solar charge controller



Payment of solar charge controller

Payment Term



T/T
EXW

30% T/T in advance, paid the balance before shipment
FOB
CFR(C&F)

30% T/T in advance, paid the balance against copy of B/L
CIF
L/C
L/C amount above 50,000 usd, we can accept L/C at sight
West Union

Amount lower than 5000usd
West Union
Delivery Time
7~10days after receiving payment for one container
